Downloads- PC cover with high transmittance,offering uniform and comfortable light
- Excellent aluminum reflector offers even and better light color,bringing visual comfort
- Excellent heat dissipation design for good heat dissipation to extend the lifespan of the lamp
- Housing material:Aluminum with good performance
- Powder coated surface treatment is durable and not easy to fall off
Cortar
Manufactured by
Manufactured by
Recessed
IP Rating IP44- Color Rendering Index 80
-
Standard Warranty
Recessed
IP Rating
Standard WarrantyAvailable Models
| SKU | Power | CCT | Beam | IP | Finish | Dimension | Cut out | Control | Download | |
|---|---|---|---|---|---|---|---|---|---|---|
 | 14934 | 20W | 3000K | 30° | IP44 | White + Iron Grey | D: 162mm x H: 119mm | 102x102mm | On or Off | Datasheet IES File |
 | 16215 | 15W | 3000K | 36° | IP44 | White + Iron Grey | D: 162mm x H: 119mm | 102x102mm | On or Off | Datasheet IES File |
 | 14933 | 10W | 3000K | 30° | IP44 | White + Iron Grey | D: 133mm x H: 103mm | 72x72mm | On or Off | Datasheet IES File |
Specifications
| Name | Cortar | Material | Aluminium Alloy |
| Type | Trimless Spotlight | Warranty | 6 Years |
| Lamp Type | CREE LED | Manufactured by | SYV |
| Name | Cortar |
| Type | Trimless Spotlight |
| Lamp Type | CREE LED |
| Material | Aluminium Alloy |
| Warranty | 6 Years |
| Manufactured by | SYV |
Downloads
Suitable for
Residential
Commercial
Hospitality
Retail
Education
